Pramac GA10000 10kVA LPG / Gas Residential Backup Generator

RELIABLE. LONG LASTING. ECO-FRIENDLY.

The Pramac GA10000 10 KVA Bi-Fuel Generator is a robust and economical backup power system for use in residential applications. It’s easy to install and use, thanks to its compact design, low levels of noise and vibration, easy maintenance, and advanced technology that’s environmentally friendly.

The robust Generac G-Force engine easily produces 10KVA / 10KW of power, efficiently delivering it to your home. Its compact size makes it perfect for personal use and its quiet operation is suitable for residential use. Durable and reliable, this generator will keep you powered during any problem with the electrical grid.

With the latest DSP (digital signal processing) technology, it automatically adjusts power output to reduce noise and ensure smooth operation of sensitive electrical equipment. It’s Overhead Valve (OHV) design means increased efficiency, reliability and low fuel consumption.

The Pramac GA10000 is a very powerful backup generator. It has 10kVA backup power for up to 4 days in emergency situations, and you can choose between running on Liquid Propane (LP) or Natural Gas (NG). It has low fuel consumption with just 3.51 (m3/h) NG and 4.79 (kg/h) LPG @ 50% load!

Featuring a digital control panel for full operational control, alerts codes and more besides, this is a generator you can rely on. Better yet, you can always know the status of your gas generator anytime, anywhere with the Wi-Fi Mobile Link™ mobile remote monitoring system and app. It's equipped with an hour meter and seven-day exerciser to keep it tip top condition as well as an easy start system.

Prepare for the unexpected this winter! Backup generators provide essential power in case of emergencies, so you can feel safe and secure during a power outage. With the flexibility to add additional appliances, you are leaving nothing to chance.

Features and Benefits

Engine

• Generac G- Force design: Maximizes engine “breathing” for increased fuel efficiency. Plateau honed cylinder walls and plasma moly rings helps the engine run cooler, reducing oil consumption resulting in longer engine life.
• “Spiny-lok” cast iron cylinder walls: Rigid construction and added durability provide long engine life.
• Electronic ignition/spark advance: These features combine to assure smooth, quick starting every time.
• Full pressure lubrication system: Pressurized lubrication to all vital bearings means better performance, less maintenance and longer engine life. Now featuring up to a 2 year/200 hour oil change interval.
• Low oil pressure shutdown system: Shutdown protection prevents catastrophic engine damage due to low oil.
• High temperature shutdown: Prevents damage due to overheating.

Generator

• Revolving field: Allows for a smaller, light weight unit that operates 25% more efficiently than a revolving armature generator.
• Skewed stator: Produces a smooth output waveform for compatibility with electronic equipment.
• Displaced phase excitation: Maximizes motor starting capability.
• Automatic voltage regulation: Regulates the output voltage to ±1% prevents damaging voltage spikes.
• True Power Technology: Less than 5% total harmonic distortion (THD).

Evolution™ Controls

• Auto/Manual/Off illuminated buttons: Selects the operating mode and provides easy, at-a-glance status indication in any condition.
• Sealed, raised buttons: Smooth, weather-resistant user interface for programming andoperations.
• Utility voltage sensing: Constantly monitors utility voltage, setpoints 65% dropout, 80%pick-up, of standard voltage.
• Utility interrupt delay: Prevents nuisance start-ups of the engine, adjustable 2-1500 seconds from the factory default setting of 5 seconds by a qualified dealer.
• Engine warm-up: Ensures engine is ready to assume the load, setpoint approximately 5 seconds.
• Engine cool-down: Allows engine to cool prior to shutdown, setpoint approximately 1 minute.
• Programmable seven day exercise: Operates engine to prevent oil seal drying and damage between power outages by running the generator for 5 minutes every other week. Also offers a selectable setting for weekly or monthly operation providing flexibility and potentially lower fuel costs to the owner.
• Smart battery charger: Delivers charge to the battery only when needed at varying rates depending on outdoor air temperature. Compatible with lead acid and AGM-style batteries.
• Main line circuit breaker: Protects generator from overload.
• Electronic governor: Maintains constant 50 Hz frequency.
• Wi-Fi Connectivity Unit
• Weather protective Aluminum Enclosure: Sound attenuated enclosures ensure quiet operation and protection against mother nature, with standing winds up to 240km/h. Hinged key locking roof panel for security. Lift-out front for easy access to all routine maintenance items. Electrostatically applied textured epoxy paint for added durability.
• Enclosed muffler: Quiet, critical grade muffler is mounted inside the unit to prevent injuries.
• Small, compact, attractive: Makes for an easy, eye appealing installation.

Installation System

• 305 mm flexible fuel line connector: Absorbs any generator vibration when connected to rigid pipe.
• Direct-to-dirt composite mounting pad: Complex lattice design prevents settling or sinking of the generator system.
• Integral sediment trap: Prevents particles and moisture from entering the fuel regulator and engine, prolonging engine life.
